k.AIR

P+DA0*, P+5A0*

k.AIR

General characteristics

k.Air is the ready-to-use solution for managing air handling and ventilation units.

k.Air is a preprogrammed and fully-configurable controller, designed to reduce times and costs, from design right through to commissioning. It offers considerable flexibility, so as manage as many applications as possible, from the simplest to the most complex unit.

The distinctive feature of k.Air is the result of CAREL's extensive experience in air handling unit and humidification management applications. Its intelligent control logic in fact ensures comfort, indoor air quality and a healthy environment, always with the lowest energy consumption, through hygienic and efficient operation of all of the components of the air handling unit.

k.Air offers an advanced user experience: simplified access to information for users and service via an integrated web interface. A set of graphic pages with unit dashboards are available from first start-up, ready to be used with the new pGDx family of touchscreen displays.

Plus

	Flexibility A single application with modular architecture, designed to adapt to a wide range of application layouts.
	Plug&play Easy configuration and commissioning. Pre-loaded configurations; Custom configurations generated by an external tool; Auto-Backup of the last active configuration; Manual configuration via display of all the unit's components;
	Connectivity Simplified integration, both in the field with the unit's components, and integration with higher-level supervisory systems or BMS via built-in serial and Ethernet communication. Standard building automation protocols such as Modbus and BACnet are native in the controller.
	Usability Built-in web interface with graphic pages and dashboards.
	Air quality and hygiene Indoor air quality control Accurate control of isothermal and adiabatic humidification VDI-6022 program, with functions to improve unit hygiene based on the requirements of the VDI standard
	Energy efficiency Smart device management based on minimum energy consumption Freecooling, freeheating, heat recovery and indirect evaporative cooling Management of direct expansion systems with DC compressors and EEV synchronisation

Documentation

Technical

Manuals

Code	Description	Language	Date *	Release
Code +030220980	Description k.Air Controllo per unità di trattamento aria	Language ITA	Date 04/10/2023	Release 1.5
Code +030220981	Description k.Air Air handling unit controller	Language ENG	Date 04/10/2023	Release 1.5
Code +030220982	Description k.Air Commande pour unités de traitement d’air	Language FRE	Date 04/10/2023	Release 1.5
Code +030220984	Description k.Air Control para unidades de tratamiento del aire	Language SPA	Date 04/10/2023	Release 1.5

Technical Leaflets

Code	Description	Language	Date *	Release
Code +0500135IE	Description P+5A0SFCLK, P+DA00FHDFK: k.Air - kit per controllo unità trattamento aria e ventilazione / kit for air handling and ventilation unit control	Language ENG ITA	Date 04/10/2023	Release 1.2

Commercial

Other related documentation

Code	Description	Language	Date *	Release
Code +800004030	Description Soluzioni per Unità Trattamento Aria: Tecnologia e competenza per la qualità dell’aria e il risparmio energetico	Language ITA	Date 05/04/2023	Release 1.2
Code +800004031	Description Solutions for Air Handling Units: Technology and expertise for indoor air quality and energy saving	Language ENG	Date 05/04/2023	Release 1.2
Code +800004036	Description Rozwiązania dla central wentylacyjno-klimatyzacyjnych (AHU) - Technologia, doświadczenie i oszczędność energii dla jakości powietrza w pomieszczeniach	Language POL	Date 05/04/2023	Release 1.2

Images

High resolution images

Code	Description	Language	Date *	Release
Code PH18LP+307-kAir-range	Description kAir-CAREL-HVAC controls-Air Handling and Ventilation	Language ALL	Date 01/09/2021	Release R.0
